Energreen New Speed Cutting Head Attachment

Energreen
NEW SPEED
Cutting Head

Brochure

Energreen NEW SPEED is a robust and reliable cutting head, ideal for cutting grass and shrub up to 3,14 inch in diameter. It’s available in 47,24 inch and 59,05 inch sizes. The structural characteristic allows to used/mount six different types of rotor (knives, hammers, multi-purpose knives Y, etc.), to work in different environments, from green maintenance to forest use. The rotors can be quickly replaced by one operator. The double direction of the rotation of the rotor with an additional application of the 180° rotating wheel (optional), allow to work in both directions, optimizing working times.

TECHNICAL DATA NEW SPEED 120 (47 in) NEW SPEED 150 (59 in)
Width 55 in 66 in
Depth 37 in 37 in
Height 22 in 22 in
Working Width 44 in 56 in
Engine 44 cc/350 bar/5076 PSI 44 cc/350 bar/5076 PSI
Transmission Belt Belt
Maximum Power 60/70 Hp (44/51,5 kW) 65/75 Hp (48/55 kW)
Rotor Diameter 5 in 5 in
Rotor Speed 3000 rpm 3000 rpm
No. Knives
Multipurpose + Straight		 32 + 16 44 + 22
No. Hammers 22 26
No. Articulated Flails 48 72
Total Weight (standard) 705 lbs 837 lbs
Total Weight with Slewing Bearing (optional) 837 lbs 970 lbs
